50W-200W LED Tunnel Light

TypeLED Tunnel Lights
ModelOPL-SDD7203
CCT3000K/4000K/5000K/5700K
Luminous Efficiency100
Categories: , SKU: OPL-SDD7203

Description

  1. 1. Lamp body made of stretch aluminium, modular design, impact resistant, corrosion resistant;
  2. 2. Uses the thermal honeycomb principle and full structural cooling technology to achieve superior heat dissipation;
  3. 3. IP67 rated, dust and waterproof;
  4. 4. non wire eutectic welding, avoids disconnection from broken wires;
  5. 5. One damaged light bead won’t affect other light beads current;
  6. 6. Intelligent constant current driver technology, overcoming the power supply service life bottleneck;
  7. 7. Ergonomic light distribution, uniform illumination;
  8. 8. Customisable all power level solution.

Product Specifications

ModelOPL-SDD7203-100WOPL-SDD7203-150WOPL-SDD7203-200W
Operating VoltageAC100-277AC100-277AC100-277
Power Efficiency0.910.910.91
CRI (Ra)>70>70>70
CCT (K)3000K/4000K/5000K/5700K3000K/4000K/5000K/5700K3000K/4000K/5000K/5700K
Power Factor0.950.950.95
Junction Temperature<80°C<80°C<80°C
MaterialsAluminum alloyAluminum alloyAluminum alloy
Operating Environment-40°C ~+ 50°C 10%~90%RH-40°C ~+ 50°C 10%~90%RH-40°C ~+ 50°C 10%~90%RH
Life Expectancy>50000h>50000h>50000h
Light DistributionBatwing distribution; Equal brightness distributionBatwing distribution; Equal brightness distributionBatwing distribution; Equal brightness distribution
Light SourcePhilips LumiledsPhilips LumiledsPhilips Lumileds
Protection LevelIP67IP67IP67
System Power (W)100150200
Luminous efficiency (lm/w)100100100
Initial Luminous Flux (lm)100001500020000
Product Dimensions L*W*H (mm)279*150*191279*230*191279*310*191

Light Distribution Curve

Product Specifications

ModelOPL-SDD7203-100WOPL-SDD7203-150WOPL-SDD7203-200W
Operating VoltageAC100-277AC100-277AC100-277
Power Efficiency0.910.910.91
CRI (Ra)>70>70>70
CCT (K)3000K/4000K/5000K/5700K3000K/4000K/5000K/5700K3000K/4000K/5000K/5700K
Power Factor0.950.950.95
Junction Temperature<80°C<80°C<80°C
MaterialsAluminum alloyAluminum alloyAluminum alloy
Operating Environment-40°C ~+ 50°C 10%~90%RH-40°C ~+ 50°C 10%~90%RH-40°C ~+ 50°C 10%~90%RH
Life Expectancy>50000h>50000h>50000h
Light DistributionBatwing distribution; Equal brightness distributionBatwing distribution; Equal brightness distributionBatwing distribution; Equal brightness distribution
Light SourcePhilips LumiledsPhilips LumiledsPhilips Lumileds
Protection LevelIP67IP67IP67
System Power (W)100150200
Luminous efficiency (lm/w)100100100
Initial Luminous Flux (lm)100001500020000
Product Dimensions L*W*H (mm)279*150*191279*230*191279*310*191
